Manatec Wheel Balancer DL-65 Premium 1

Manatec Wheel Balancer DL-65 Premium 1 Specification

Length
1400 mm

Used For
Car and LCV Wheels

Operate Method
Automatic

Product Type
Wheel Balancer

Width
1200 mm

Working Voltage
220V AC, 50 Hz

Size
Standard

Power Source
Electric

Motor Power
0.25 kW

Usage
Garage, Tire Shops, Automobile Workshops

Material
Metal and ABS Plastic

Color
Black & Grey

Rim Width Range
1.5 20

Accessory Kit
Includes cones, quick release nut, caliper, and weight pliers

Net Weight
98 kg

Automatic Data Entry
Touchless (rim distance, rim diameter, rim width)

Display Type
LED Digital

Max Wheel Weight
65 kg

Model Name
DL-65 Premium 1

Input Voltage
220V 10% / 1Ph / 50Hz

Measuring Speed
200 rpm

Gross Weight
120 kg

Balancing Precision
1g

Calibration Mode
Semi-automatic

Rim Diameter Range
10 24

User Interface
Soft Touch Controls

Brake Type
Automatic

Noise Level
<70 dB(A)

Manatec Wheel Balancer DL-65 Premium 1 Trade Information

Minimum Order Quantity
1 Piece

Payment Terms
Cheque, Cash on Delivery (COD), Cash Advance (CA)

Sample Available
Yes

Main Domestic Market
Rajasthan

About Manatec Wheel Balancer DL-65 Premium 1

Suitable for car and LCV wheels Two modes of measurement normal fine seven modes of alloy wheel function graphical user interface for live balancing option for grams ounces unit conversion .

Laser line indication to indicate weight fixing position for sticker weight torch light for illumination of the inner plane during weight fixing.

Type	Fully Automatic
Model Name/Number	WB-VL-65 DSP lx
Brand	Manatec
Type Of Vehicle	Cars
Power Supply	220v
Rim Diameter	10"-24"

Advanced Touchless Data Entry

DL-65 Premium 1 utilizes touchless technology for automatic input of rim distance, diameter, and width, reducing user error and speeding up the balancing process. This advanced feature enhances both precision and ease-of-use for busy workshops.

LED Digital Display and User-Friendly Interface

Equipped with an LED digital screen and soft touch controls, this wheel balancer ensures clear data visualization and intuitive operation. The interface accelerates workflow, allowing operators to quickly adapt to the machine.

Built for Professional Performance

With robust construction and features such as automatic brake and semi-automatic calibration, the DL-65 Premium 1 is designed for high-volume use in garages, tire shops, and automobile workshops. Its swift 200 rpm measuring speed and 1g precision ensure top-tier results.

FAQ's of Manatec Wheel Balancer DL-65 Premium 1:

Q: How does the touchless automatic data entry work on the DL-65 Premium 1?

A: The DL-65 Premium 1 is equipped with advanced sensors that automatically measure and input rim distance, diameter, and width without manual intervention. This feature increases efficiency and reduces human error during the balancing process.

Q: What wheel sizes can this wheel balancer accommodate?

A: This model supports rims with diameters ranging from 10 to 24 inches and widths from 1.5 to 20 inches. It can handle wheels weighing up to 65 kg, covering most cars and light commercial vehicles.

Q: Where is the DL-65 Premium 1 typically used?

A: It is ideal for professional environments such as garages, tire shops, and automobile workshops-especially where high throughput and accuracy are required. The machine is also widely distributed and supported across India.

Q: What is the process for balancing a wheel with this unit?

A: To balance a wheel, mount it using the included accessory kit, allow the machine to auto-detect rim data, and then follow prompts on the LED display. The system measures imbalance at 200 rpm and provides corrective weight placement instructions.

Q: What are the main benefits of using the DL-65 Premium 1?

A: Key benefits include rapid, precise balancing (1g accuracy), efficient operation via touchless controls and digital interface, and a durable build suited for frequent use. Its automatic features reduce setup time and ensure reliable results.

Q: What power supply does the machine require?

A: The DL-65 Premium 1 operates on a standard 220V AC, 50 Hz single-phase supply with a power input of 0.25 kW, making it compatible with most workshop environments.
